| Printer specification parameter table | ||
| project | Project Description | Specifications |
| Printing Features | Printing method | Direct Thermal |
| Resolution | 203DPI(Label ) 384Point/line(receipt) | |
| Max.print speed | ≤70mm/s(Label) 70mm/s(receipt) | |
| Max.print width | 20-80mm(Label ) 80mm(receipt) | |
| Media | Media type | Thermosensitiveadhesive(Label ) Thermalpaper(receipt) |
| Media width | 20 mm~80mm | |
| Outer diameter of paper coupon | ≤50 mm | |
| Performance Features | Processor | 32-bit CPU |
| Memory | 8MB Flash Memory /512KMB SDRAM/ | |
| Interface | USB+Bluetooth | |
| Fonts/Graphics/Symbclogics | Font and barcode rotation | 0° / 90° / 180° / 270° |
| 1D barcode | 1D bar code:Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST | |
| 2D bar code | PDF-417, QR code | |
| Physical Features | Dimension | W*H*D:109.94-62.2-123.5 |
| Weight | 0.34kg | |
| Reliability | Printer head life | 30 KM |
| Software | Operation system | Windows / Linux / Android / IOS |
| SDK | Windows / Linux / Android / IOS | |
| Power supply | Power input | DC 5V/2A |
