Printing Features
Resolution	203 DPI
Printing method	Thermal Transfer / Direct Thermal
Max.print speed	127 mm (5”) / s Max.
Max.print width	108 mm (4.25")
Max.print length	2286 mm (90”)
Media
Media type	Continuous, gap, black mark, fan-fold and punched hole
Media width	25.4-118mm (1.0”-4.6”)
Media thickness	0.06~0.254 mm (2.36~10mil)
Media core diameter	25.4 ~ 76.2 mm (1 "~ 3 ")
Label length	10 ~ 2286 mm(0.39" ~ 90" )
Label roll capacity	127 mm (5“) (External diameter)
Ribbon capacity	Max.300 m
Ribbon width	110 mm
Ribbon core inner diameter	25.4 mm (1")
Performance Features
Processor	32-bit CPU
Memory	4MB Flash Memory, 8MB SDRAM, SD card reader for Flash memory expansion, up to 4 GB
Interface	Standard: USB+TF card Optional: Serial/Lan/Bluetooth/WIFI/Parallel
Fonts/Graphics/Symbologies
Internal fonts	8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software.
1D barcode	Code 39, Code 93, Code 128UCC, Code 128 ，subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on,Standard 2-of-5,Industrial 2-of-5, Planet Code
1D barcode	MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11
2D barcode	PDF-417, Maxicode, DataMatrix, QR code, Aztec，Codablock, Code 49, Micro PDF417
Rotation	0°、90°、180°、270°
Emulaion	TSPL、EPL、ZPL、DPL
Physical Features
Dimension	302.5 mm (D) x 234 mm (W) x 194.8 mm (H)
Weight	2.6kg
Reliability
Print head life	30 km
Software
Driver	Windows/Linux/Mac
SDK	Windows/Android/iOS
Power supply
Input：AC 100-240V,1.8A, 50-60Hz
Output：DC 24V, 2.5A, 60W
Options
Factory Options	① Peeler
Factory Options	② Cutter
Dealer Options	①External paper roll holder and 1"paper roll spindle
	②Bluetooth module (RS-232C transmission interface)
	③WIFI module
	④Extension board for external paper roll holder
Environmental Conditions
Operation	5 ~ 40°C（41~104°F），Humidity: 25 ~ 85% non-condensing
Storage environment	-40 ~ 60°C（-40~140°F），Humidity:10 ~ 90% non-condensing
